Stepdeck Semi-Trailer

Built for low loading height.

Key features

Stepped low deck
A lower working height for taller cargo and overall transport height.
4.5 mm steel deck
Supports demanding machinery and plant loads.
Hydraulic ramps
A dedicated power pack loads and unloads machinery efficiently.
Outriggers, chainrings, container locks
Added stability and load security for heavy haulage.

Carries

Heavy machinery
Plant equipment
Containers
Oversized loads

Payload: 30,540kg
Gross combination mass: 49,500kg
Tare weight: 9,460kg
Deck length: 14.95m

Reference figures for each configuration, taken from manufacturer specifications. Payloads assume a truck tare of about 9 500 kg. Actual payload, tare and dimensions vary with the truck, the body build and permit conditions; our bookings team confirms the vehicle for your load before it is booked.

Technical specification

Stepdeck Semi-Trailer: Weights & capacity
Weights & capacity
Configuration	14.95 m tridem-axle stepdeck semi-trailer
Payload	30,540 kg
Gross combination mass	49,500 kg
Tare weight	9,460 kg

Stepdeck Semi-Trailer: Overall dimensions
Overall dimensions
Trailer length	14,952 mm
Overall width	2,600 mm
Deck height	1,154 mm

Stepdeck Semi-Trailer: Chassis & running gear
Chassis & running gear
Wheels	275/70 R22.5
Rims	8.25 × 22.5 offset aluminium
Suspension	Mechanical suspension
Braking system	Twin-line brakes with 24 V ABS
Spare-wheel carrier	Bolt-on type
Standard features	4.5 mm steel deck, hydraulically operated ramps with power pack, container locks, chainrings and outriggers
